首頁 > 產品資訊 > M.2 (NGFF)介面 > M2MP1

    M2MP1-A
M.2 (NGFF) 轉 mPCIe (PCIe+USB) 轉接板
(Socket 1 , Key A)

    M2MP1-E
M.2 (NGFF) 轉 mPCIe (PCIe+USB) 轉接板
(Socket 1 , Key E)





Brief Taiwan 1 Taiwan 2 China
Web-shop




連絡業務

M2MP1-E 批量採購

100pcs 500pcs 1000pcs
30.
USD / Piece
20.
USD / Piece
12.
USD / Piece


概要


名稱 (Name) : M2MP1-A
簡介 (Summary) : M.2 (NGFF) to mPCIe (PCIe+USB) adapter
界面 (Interface):  mPCIe side: PCIe + USB
M.2 (NGFF) side : Key A Socket 1
應用 (Application) :  Suitable for intel 7260NGW with 802.11ac WiFi & Bluetooth 4.0

名稱 (Name) : M2MP1-E
簡介 (Summary) : M.2 (NGFF) to mPCIe (PCIe+USB) adapter
界面 (Interface):  mPCIe side: PCIe + USB
M.2 (NGFF) side : Key E Socket 1
應用 (Application) :  Suitable for intel 7260NGW with 802.11ac WiFi & Bluetooth 4.0



    產品功能


  • Allows user to use M.2 Socket 1 Module to mPCIe Slot in the Desktop or Laptop.
  • Supports system bus interface: PCIe&USB2.0.
  • Supports USB interface of Mini-Cards such as 3G,CDMA, WWAN, HSPA, GPS, WiMAX, Bluetooth Mini Card to desktop PC.
  • Support PCIeMiniCard :IEEE WLAN802.11a/b/g/n, 802.11d, 802.11e, 802.11i, 802.11h, 802.11ac
  • No drivers needed for this M.2 to mini PCI-E Card Adapter



    產品規格


  • M.2 Specification Revision 0.9-3
  • PCI Express base Specification 1.1 (Up to 2.5Gpbs)
  • USB Specification Revision2.0
  • Support 3030/3042 M.2 Card dimension.
  • Support M.2 Socket 1 Module.
  • M2MP1-A Support M.2 Key A / A+E Card Type.
  • M2MP1-E Support M.2 Key E / A+E Card Type.
  • Support Full size and half size mPCIe slot

    系統需求


  • Mini PCI-E slot
  • Windows 2000, XP, Vista 32/64, Windows 7, Windows 8 or Linux



M.2 (NGFF) to mini PCI-E Adapter comparison
Model Name UN32B M2BU3S-U3D M2BU3S-U2D M2BU3S-PU M2MU2
Function M.2 to mini card Rev 2.1 M.2 to mini card Rev 2.1 M.2 to mini card Rev 2.1 M.2 to mini card Rev 2.1 M.2 to mPCIe
Interface PCIe & USB 3.0 USB 3.0 USB 2.0 PCIe 2x or SATA USB 2.0
M.2 SPEC Socket 2 PCIe & USB3.0 dual bus WWAN Socket 2 SSIC-based WWAN Socket 2 SSIC-based WWAN Socket 2 Socket 2 SSIC-based WWAN
Application 5G / 4G / 3G / CDMA / LTE / GPS module 5G / 4G / CDMA / LTE / GPS module 5G / 4G / CDMA / LTE / GPS module PCIe 2x or SATA SSD module 5G / 4G / CDMA / LTE / GPS module
Module KEY B B B B B
Support Card Type 3030/3042/3050/3052 2242,50,52 / 3042,50,52 2242,50,52 / 3042,50,52 2242,50,52 / 3042,50,52 2230/2242/3030/3042

M.2 (NGFF) to mini PCI-E Adapter comparison
Model Name MN25A M2MP1-A M2MP1-E M2MP3-A M2MP3-E
Function M.2 to mPCIe M.2 to mPCIe M.2 to mPCIe M.2 to mPCIe M.2 to mPCIe
Interface PCIe & USB2.0 PCIe & USB2.0 PCIe & USB2.0 PCIe & USB2.0 PCIe & USB2.0
M.2 SPEC Socket 1
First PCIe Lane
Socket 1
First PCIe Lane
Socket 1
First PCIe Lane
Socket 1
Second PCIe Lane
Socket 1
Second PCIe Lane
Application WiFi+BT module WiFi+BT module WiFi+BT module WiFi+BT module WiFi+BT module
Module KEY E A E A E
Support Card Type 2230 2230/2242/3030/3042 2230/2242/3030/3042 2230/2242/3030/3042 2230/2242/3030/3042

mini PCI-E to M.2 (NGFF) Adapter comparison
Model Name NM51A NM61A-P01 NM61A-U3
Function mPCIe to M.2 mPCIe to M.2 mPCIe to M.2
Interface PCIe & USB2.0 PCIe USB3.0
M.2 SPEC Socket 1
First PCIe Lane
Socket 2
First PCIe Lane
Socket 2
USB3.0

Application WiFi+BT module PCIe Interface module USB Interface module
Module KEY A E B M B M
Support Card Type 3042/3050/3052/3060 3042、50、52、60、80 3042、50、52、60、80



購物車及包裝內容


M2MP1-A
售價: USD 50.
M2MP1-A
M.2 (NGFF) 轉 mPCIe (PCIe+USB) 轉接板 x1
螺絲 x4

平頭螺絲 x4




M2MP1-E-7265
售價: USD 73.
M2MP1-E V1.1
M.2 (NGFF) 轉 mPCIe (PCIe+USB) 轉接板 x1
7265NGW
(英特爾®雙頻無線-AC 7265) x1
Screw x4

Flat-Head Screw x4



M2MP1-E V1.1
售價: USD 50.
M2MP1-E V1.1
M.2 (NGFF) 轉 mPCIe (PCIe+USB) 轉接板 x1
螺絲 x4

平頭螺絲 x4




連絡業務

M2MP1-E 批量採購

100pcs 500pcs 1000pcs
30.
USD / Piece
20.
USD / Piece
12.
USD / Piece
