Home > Product > M.2 Interface > NM51A
  NM51A
mPCIe Module to M.2 A E key Adapter




Web-shop






First Impression

名稱 (Name) : NM51A
簡介 (Summary) : mPCIe (PCIe+USB) to M.2 A E key adapter
界面 (Interface):  M.2 A E key side: PCIe + USB (Socket 1)
mPCIe side : mini PCI-E (PCIe+USB)

    Function

  • Allows user to use mPCIe Module to M.2 A E key Slot in the Desktop or Laptop.
  • Supports system bus interface: PCIe & USB.
  • No drivers needed for this mini PCI-E Card to M.2 A E key Adapter

    Specifications

  • M.2 Specification Revision 1.0
  • PCI Express base Specification 1.1 (Up to 2.5Gpbs)
  • USB Specification Revision2.0
  • Support Full size and half size mPCIe card
  • Support 3042/3050/3052/3060 M.2 Card dimension slot.

    System Requirement

  • M.2 A E key slot
  • Windows or Linux



M.2 (NGFF) to mini PCI-E Adapter comparison
Model Name UN32B M2BU3S-U3D M2BU3S-U2D M2BU3S-PU M2MU2
Function M.2 to mini card Rev 2.1 M.2 to mini card Rev 2.1 M.2 to mini card Rev 2.1 M.2 to mini card Rev 2.1 M.2 to mPCIe
Interface PCIe & USB 3.0 USB 3.0 USB 2.0 PCIe 2x or SATA USB 2.0
M.2 SPEC Socket 2 PCIe & USB3.0 dual bus WWAN Socket 2 SSIC-based WWAN Socket 2 SSIC-based WWAN Socket 2 Socket 2 SSIC-based WWAN
Application 5G / 4G / 3G / CDMA / LTE / GPS module 5G / 4G / CDMA / LTE / GPS module 5G / 4G / CDMA / LTE / GPS module PCIe 2x or SATA SSD module 5G / 4G / CDMA / LTE / GPS module
Module KEY B B B B B
Support Card Type 3030/3042/3050/3052 2242,50,52 / 3042,50,52 2242,50,52 / 3042,50,52 2242,50,52 / 3042,50,52 2230/2242/3030/3042

M.2 (NGFF) to mini PCI-E Adapter comparison
Model Name MN25A M2MP1-A M2MP1-E M2MP3-A M2MP3-E
Function M.2 to mPCIe M.2 to mPCIe M.2 to mPCIe M.2 to mPCIe M.2 to mPCIe
Interface PCIe & USB2.0 PCIe & USB2.0 PCIe & USB2.0 PCIe & USB2.0 PCIe & USB2.0
M.2 SPEC Socket 1
First PCIe Lane		 Socket 1
First PCIe Lane		 Socket 1
First PCIe Lane		 Socket 1
Second PCIe Lane		 Socket 1
Second PCIe Lane
Application WiFi+BT module WiFi+BT module WiFi+BT module WiFi+BT module WiFi+BT module
Module KEY E A E A E
Support Card Type 2230 2230/2242/3030/3042 2230/2242/3030/3042 2230/2242/3030/3042 2230/2242/3030/3042

mini PCI-E to M.2 (NGFF) Adapter comparison
Model Name NM51A NM61A-P01 NM61A-U3
Function mPCIe to M.2 mPCIe to M.2 mPCIe to M.2
Interface PCIe & USB2.0 PCIe USB3.0
M.2 SPEC Socket 1
First PCIe Lane		 Socket 2
First PCIe Lane		 Socket 2
USB3.0
Application WiFi+BT module PCIe Interface module USB Interface module
Module KEY A E B M B M
Support Card Type 3042/3050/3052/3060 3042、50、52、60、80 3042、50、52、60、80



Web-shop

NM51A-P01 E11
Unit price: USD 50.
NM51A-P01 E11
mPCIe Module to M.2 A E key Adapter x1
 Screw x4
