Home > Product > M.2 Interface > NM61A
  NM61A
mPCIe Module to M.2 B M key Adapter






Web-shop






First Impression


名稱 (Name) : NM61A-P01
簡介 (Summary) : PCIe interface mPCIe card to M.2 B M key adapter
界面 (Interface):  M.2 B M key side:First PCIe Lane interface
mPCIe side : mini PCI-E (PCIe)

名稱 (Name) : NM61A-U3
簡介 (Summary) :USB interface mPCIe card to M.2 B M key adapter
界面 (Interface):  M.2 B M key side: USB interface
mPCIe side : mini PCI-E (USB)

    Function


  • Allows user to use mPCIe Module to M.2 B M key Slot in the Desktop or Laptop.
  • NM61A-P01:Supports system bus interface: PCIe.
  • NM61A-U3:Supports system bus interface: USB.
  • No drivers needed for this mini PCI-E Card to M.2 B M key Adapter.

    Specifications


  • M.2 Specification Revision 1.0
  • PCI Express base Specification 1.1 (Up to 2.5Gpbs)
  • USB Specification Revision3.0
  • Support Full size and half size mPCIe card
  • Support 3042/3050/3052/3060/3080 M.2 Card dimension slot.

    System Requirement


  • M.2 B M key slot



M.2 (NGFF) to mini PCI-E Adapter comparison
Model Name UN32B M2BU3S-U3D M2BU3S-U2D M2BU3S-PU M2MU2
Function M.2 to mini card Rev 2.1 M.2 to mini card Rev 2.1 M.2 to mini card Rev 2.1 M.2 to mini card Rev 2.1 M.2 to mPCIe
Interface PCIe & USB 3.0 USB 3.0 USB 2.0 PCIe 2x or SATA USB 2.0
M.2 SPEC Socket 2 PCIe & USB3.0 dual bus WWAN Socket 2 SSIC-based WWAN Socket 2 SSIC-based WWAN Socket 2 Socket 2 SSIC-based WWAN
Application 5G / 4G / 3G / CDMA / LTE / GPS module 5G / 4G / CDMA / LTE / GPS module 5G / 4G / CDMA / LTE / GPS module PCIe 2x or SATA SSD module 5G / 4G / CDMA / LTE / GPS module
Module KEY B B B B B
Support Card Type 3030/3042/3050/3052 2242,50,52 / 3042,50,52 2242,50,52 / 3042,50,52 2242,50,52 / 3042,50,52 2230/2242/3030/3042

M.2 (NGFF) to mini PCI-E Adapter comparison
Model Name MN25A M2MP1-A M2MP1-E M2MP3-A M2MP3-E
Function M.2 to mPCIe M.2 to mPCIe M.2 to mPCIe M.2 to mPCIe M.2 to mPCIe
Interface PCIe & USB2.0 PCIe & USB2.0 PCIe & USB2.0 PCIe & USB2.0 PCIe & USB2.0
M.2 SPEC Socket 1
First PCIe Lane
Socket 1
First PCIe Lane
Socket 1
First PCIe Lane
Socket 1
Second PCIe Lane
Socket 1
Second PCIe Lane
Application WiFi+BT module WiFi+BT module WiFi+BT module WiFi+BT module WiFi+BT module
Module KEY E A E A E
Support Card Type 2230 2230/2242/3030/3042 2230/2242/3030/3042 2230/2242/3030/3042 2230/2242/3030/3042

mini PCI-E to M.2 (NGFF) Adapter comparison
Model Name NM51A NM61A-P01 NM61A-U3
Function mPCIe to M.2 mPCIe to M.2 mPCIe to M.2
Interface PCIe & USB2.0 PCIe USB3.0
M.2 SPEC Socket 1
First PCIe Lane
Socket 2
First PCIe Lane
Socket 2
USB3.0

Application WiFi+BT module PCIe Interface module USB Interface module
Module KEY A E B M B M
Support Card Type 3042/3050/3052/3060 3042、50、52、60、80 3042、50、52、60、80



Web-shop


NM61A-P01 E10A
Unit price: USD 50.
NM61A-P01 E10A
PCIe interface mPCIe card to M.2 B M key adapter x1
Screw x4





NM61A-U3 E10A
Unit price: USD 50.
NM61A-U3 E10A
USB interface mPCIe card to M.2 B M key adapter x1
Screw x4





Buy Related Items


NM51A
M2MP1-E
M2MP3-A
M2MP3-E
