Home > Product > Extender Board > P28S-P28F

    P28S-P28F
PCI-Express to MiniCard Extender



Brief Taiwan 1 Taiwan 2 China
Dimension Taiwan 1 Taiwan 2 China
3D Model Taiwan 1 Taiwan 2 China
Schematic Taiwan 1 Taiwan 2 China
Selection Guide Taiwan 1 Taiwan 2 China
Buy It Now


First Impression

P28S-P28F Extender is a debug and test tool to extend PCI-Express slot from MiniCard (mPCIe) slot. Design the FFC (Flat Flexible Cable) cable for flexible use.
Not only for Full-size MiniCard adapter but also Half-size MiniCard by removing extra Full-size extensions.

The extender is designed to minimize the signal degradation effects of the extender by proven design techniques. It’s also a powerful tool for engineers and factory tests.




Warning:
If MiniCard slot on the host does not support PCIe interface, the interface can not be supported.
Other PCIe speed of PCIe2.0 (5Gbps)/PCIe3.0(10Gbps) is not guaranteed.

      Function

  • Easy Installation, Plug and Play
  • No drivers needed for this MiniCard to ExpressCard Adapter
  • Support Windows 2000/Server 2003/XP & XP 64-bit/Vista & Vista 64-bit/ 7 & 7 64-bit
  • Supports PCI Express based MiniCard slot
  • Miscellaneous: WAKE#, PERST#
  • Support external 12V power supply by pin header

      Specification

  • PCI Express™ Mini Card Electromechanical Specification Revision 1.0
  • PCI Express base Specification 1.1 (Up to 2.5Gpbs)
  • System Management Bus (SMBus) Specification, Version 1.1
  • PCI Express Card Electromechanical (CEM) Specification 1.1



Package Content

P28S-P28F
Unit price: USD 36.
P28S x1
 P28F x1
 FFC0536P-010A (FFC cable 10cm) x1
FFC0536P-020A (FFC cable 20cm) x1
FFC0536P-030A (FFC cable 30cm) x1
 Screw x2

Buy Related Items

P24S-P24F
P21S-P21F
