    P21S-P21F
(Flexible x1 PCI Express Extender)


Introduction:
P21S-P21F PCI Express Extender is a debug and test tool. Design the FFC (Flat Flexible Cable) cable for flexible use.
As PCI Express x1 connector is edge-free / multi-lane, x4, x8 and x16 PCIe Cards are also available.
The PCI-Eextender is designed to minimize the signal degradation effects of the extender by proven design techniques.
It’s also a powerful tool for engineers,or use for PCI-E test protection.

 3D Model



OPTION: FFC0536P-050B (FFC cable 50cm)
The PCIe Tx and Rx signal is reverse between P21SR-P21FR (KZ-B21 V1.0R) and P21-P21F (KZ-B21 V1.1)
Application 1. P21S-P21SR : PCIe 1X to PCIe 1X Extender
Application 2. P21S-P21S : PCIe 1X to PCIe 1X Extender
Application 3. P21F-P21FR : PCIe slot (Edge Free) to PCIe Slot (Edge Free) Extender
Application 4. P21F-P21F : PCIe slot (Edge Free) to PCIe Slot (Edge Free) Extender

*Blue belt: Upper Side

*Blue belt: Upper Side



P21SR-P21FR
Unit price: USD 32.
P21SR x1
P21FR
x1
with
FFC0536P-010B x1
FFC0536P-020B x1
P21S-P21F
Unit price: USD 32.
P21S x1
P21F
x1
with
FFC0536P-010B x1
FFC0536P-020B x1
P21S-P21F-D180
Unit price: USD 32.
P21S x1
P21F-D180
x1
with
FFC0536P-010B x1
FFC0536P-020B x1
FFC0536P-050B
Unit price: USD 6.
FFC0536P-050B (FFC cable 50cm) x1




Documents Download
Brief   Taiwan   Taiwan 2 Mirror   China Mirror
Selection Guide   Tawan   Taiwan 2 Mirror   China Mirror
