    P14S-P14FP
M.2 (NGFF) to PCIe X2 Edge Extender Board





Brief Taiwan 1 Taiwan 2 China
Selection Guide Taiwan 1 Taiwan 2 China
Web-shop


    First Impression


M.2 stands for Next Generation Form Factor which is invented for PCI-SIG by Intel and it is developed for flat and high-efficiency equipment such as Ultrabook™ or Tablet PCs. It is a natural transition from the Mini Card and Half Mini Card to a smaller form factor in both size and volume which supports multiple function add-in cards/modules including: Wi-Fi, Bluetooth, global navigation satellite systems, near field communication, Hybrid digital radio, wireless gigabit alliance (WiGig), wireless wide area network and solid-state storage devices. Also adds functionality to USB 3.0, display Port, SDIO and SSD-PCIe.

The P14S-P14FP adapter is designed for desktop/Laptop PCs that convert PCI-E X2 cards.
You can insert PCI-E cards to this adapter .
It’s a powerful tool for engineers and factory tests.




      Function


  • Allows user to use PCI-E X2 Card to M.2 Socket in the Desktop or Laptop.
  • As PCI Express x4 connector is edge-free / multi-lane, x4, x8 and x16 PCIe Cards are also available.
  • No drivers needed for this mini PCI-E to M.2 Card Adapter
  • 0°C to +80°C

      Specification


  • PCI Express base Specification 1.1 (Up to 2.5Gpbs)
  • M.2 Specification Revision 0.9 Socket 1
  • Support 2230/2242/2260/2280 M.2 Card dimension.
  • Support M.2 Key B-M Card Type.

      Requirements


  • M.2(NGFF) card slot (Socket 2)



    Web-shop


P14S-P14FP
Unit price: USD 120.
P14S x1
P14FP x1
FFC0536P-010A (FFC cable 10cm) x1
FFC0536P-020A (FFC cable 20cm) x1
FFC0536P-030A (FFC cable 30cm) x1
Y02-D01-060
(Dupont 2PIN Cable) x1
Flat-Head Screw x1
