    P11S-P11F
M.2 (NGFF) to PCI-E Extender Board





Brief Taiwan 1 Taiwan 2 China
Selection Guide Taiwan 1 Taiwan 2 China
Buy It Now


First Impression



M.2 stands for Next Generation Form Factor which is invented for PCI-SIG by Intel and it is developed for flat and high-efficiency equipment such as Ultrabook™ or Tablet PCs. It is a natural transition from the Mini Card and Half Mini Card to a smaller form factor in both size and volume which supports multiple function add-in cards/modules including: Wi-Fi, Bluetooth, global navigation satellite systems, near field communication, Hybrid digital radio, wireless gigabit alliance (WiGig), wireless wide area network and solid-state storage devices. Also adds functionality to USB 3.0, display Port, SDIO and SSD-PCIe


The P11S-P11F adapter is designed for desktop/Laptop PCs that convert Duo PCI-E cards.
 You can insert two PCI-E cards to this adapter .




Note: Second PCIe Slot (J2) is compliant with M.2 Specification. Because do not have any system in the market yet so cannot tested.


  Function


  • Allows user to use M.2 Socket SSIC-based WWAN Module to mPCIe Slot in the Desktop or Laptop.
  • Supports USB interface of M.2 Cards (Socket 2 SSIC-base WWAN) such as 2G GSM, GPRS, 3G,CDMA, WLAN,WWLAN, HSPA MODEM , GPS, 4G WiMAX, LTE, Mini Card to desktop PC.
  • Support Duo PCIe x1 slot

  Specification


  • USB M.2 Card to mPCIe adapter.
  • M.2 Specification Revision 0.9
  • Universal Serial Bus Specification Revision 2.0
  • Support 2230/2242 M.2 Card dimension.
  • Support M.2 Socket SSIC-based WWAN Module.
  • Support M.2 Key A-E Card Type.



Package Content


P11S-P11F
Unit price: USD 120.
P11S x1
P11F
x1
FFC0536P-010A (FFC cable 10cm) x1
FFC0536P-020A (FFC cable 20cm) x1
FFC0536P-030A (FFC cable 30cm) x1
Y02-D01-060
(Dupont 2PIN Cable) x1
Flat-Head Screw x1

Buy Related Items


L12S
