  UN32B
M.2 key B PCIe & USB 3.0 dual bus module to mini card Rev 2.1 Adapter






Buy It Now


    產品概要


The UN32B adapter is designed for desktop/Laptop PCs that convert 5G/4G/3G WWAN M.2 Socket 2 key B PCIe & USB 3.0 dual bus module to full mini card Rev 2.1 slot.
 You can insert your M.2 card (Socket 2 WWAN) such as 5G,4G, LTE cards to this adapter .



        產品功能


  • Allows user to use M.2 Socket 2 WWAN Module to mPCIe Slot in the Desktop or Laptop.
  • Supports PCIe & USB 3.0 interface of M.2 Cards (Socket 2 WWAN) such as 5G, 4G, LTE, Mini Card to desktop PC.
  • Support Full size mPCIe slot.



        產品規格


  • PCIe & USB 3.0 M.2 B key Card to mini card Rev 2.1 adapter.
  • M.2 Specification Revision 1.0
  • Universal Serial Bus Specification Revision 3.0
  • Support 3030/3042/3050/3052 M.2 Card dimension.
  • Support M.2 Socket 2 PCIe & USB 3.0 dual bus WWAN Module.
  • Support M.2 Socket 2 Key B Card Type.
  • Support Dual SIM Card.



M.2 (NGFF) to mini PCI-E Adapter comparison
Model Name UN32B M2BU3S-U3D M2BU3S-U2D M2BU3S-PU M2MU2
Function M.2 to mini card Rev 2.1 M.2 to mini card Rev 2.1 M.2 to mini card Rev 2.1 M.2 to mini card Rev 2.1 M.2 to mPCIe
Interface PCIe & USB 3.0 USB 3.0 USB 2.0 PCIe 2x or SATA USB 2.0
M.2 SPEC Socket 2 PCIe & USB3.0 dual bus WWAN Socket 2 SSIC-based WWAN Socket 2 SSIC-based WWAN Socket 2 Socket 2 SSIC-based WWAN
Application 5G / 4G / 3G / CDMA / LTE / GPS module 5G / 4G / CDMA / LTE / GPS module 5G / 4G / CDMA / LTE / GPS module PCIe 2x or SATA SSD module 5G / 4G / CDMA / LTE / GPS module
Module KEY B B B B B
Support Card Type 3030/3042/3050/3052 2242,50,52 / 3042,50,52 2242,50,52 / 3042,50,52 2242,50,52 / 3042,50,52 2230/2242/3030/3042

M.2 (NGFF) to mini PCI-E Adapter comparison
Model Name MN25A M2MP1-A M2MP1-E M2MP3-A M2MP3-E
Function M.2 to mPCIe M.2 to mPCIe M.2 to mPCIe M.2 to mPCIe M.2 to mPCIe
Interface PCIe & USB2.0 PCIe & USB2.0 PCIe & USB2.0 PCIe & USB2.0 PCIe & USB2.0
M.2 SPEC Socket 1
First PCIe Lane
Socket 1
First PCIe Lane
Socket 1
First PCIe Lane
Socket 1
Second PCIe Lane
Socket 1
Second PCIe Lane
Application WiFi+BT module WiFi+BT module WiFi+BT module WiFi+BT module WiFi+BT module
Module KEY E A E A E
Support Card Type 2230 2230/2242/3030/3042 2230/2242/3030/3042 2230/2242/3030/3042 2230/2242/3030/3042

mini PCI-E to M.2 (NGFF) Adapter comparison
Model Name NM51A NM61A-P01 NM61A-U3
Function mPCIe to M.2 mPCIe to M.2 mPCIe to M.2
Interface PCIe & USB2.0 PCIe USB3.0
M.2 SPEC Socket 1
First PCIe Lane
Socket 2
First PCIe Lane
Socket 2
USB3.0

Application WiFi+BT module PCIe Interface module USB Interface module
Module KEY A E B M B M
Support Card Type 3042/3050/3052/3060 3042、50、52、60、80 3042、50、52、60、80



購物車及包裝內容




UN32B-F1 E11
售價: USD 70.

UN32B PCBA E11
M.2 key B PCIe & USB 3.0 dual bus module to mini card Rev 2.1 Adapter x1
with Dual SIM Card slot
Y09-U10-060
( 9Pin 1.5 Pitch Header to Type A USB3.0 cable 60cm) x1
Screw x4
Flat-Head Screw x2



UN32B PCBA E11
售價: USD 50.

UN32B PCBA E11
M.2 key B PCIe & USB 3.0 dual bus module to mini card Rev 2.1 Adapter x1
with Dual SIM Card slot
Screw x4
Flat-Head Screw x2





Y09-U10-060
售價: USD 20.

Y09-U10-060
( 9Pin 1.5 Pitch Header to Type A USB3.0 cable 60cm) x1
