  U0903A
M.2 Key B LTE Card to USB 3.0 Adapter






U0903A has ceased production and sales,
Please purchase the new product UN32A.



Brief Taiwan 1 Taiwan 2 China
Buy It Now

First Impression


The U0903A adapter is designed for desktop/Laptop PCs that convert 4G wireless M.2 Card to USB 3.0 port.
You can insert your M.2 card Key B (Socket 2 SSIC-base WWAN) such as GSM, HSPA(3.5G), GPS, LTE cards to this adapter then plug to USB 3.0 port.
Standard SIM card Push connector is provided.
U0903A supports WWAN network card with maximum 6W power consumption.



    Function


  • USB 3.0 type A male to desktop or notebook PC
  • Supports system bus interface: USB 3.0 (Micro-B Connector)
  • Supports USB 3.0 interface of M.2 Cards (Socket 2 SSIC-base WWAN) such as 2G GSM, GPRS, 3G,CDMA, WLAN,WWLAN, HSPA MODEM , GPS, 4G WiMAX, LTE, Mini Card to desktop PC.
  • Support dual SIM card Push Push connector.
  • Support MHF4-SMA 8cm cable (Option)
    Support MHF4-RPSMA 8cm cable (Option)
  • Support 3042 type M.2 card
  • Support Suspend Clock
  • Antenna Products (Click for Bplus Antenna Comparison link) :

    • (Option) 800/1800 MHz Duck Antenna
    • (Option) 900/2100 MHz Duck Antenna
    • (Option) 2.4GHz MHz 2.15dBi Rubber Duck Antenna
    • (Option) 2.4/5.8GHz Rubber Duck Antenna
    • (Option) 5.8GHz 5dBi Rubber Duck Antenna
    • (Option) 2.3GHz 2.15dBi Rubber Duck Antenna
    • (Option) 2.5GHz 2dBi Rubber Duck Antenna
    • (Option) 3.5GHz 2.5dBi Rubber Duck Antenna

    Specification


    • M.2 Card to USB3.0 adapter.
    • M.2 Specification Revision 1.0
    • Universal Serial Bus Specification Revision 3.0
    • 3042 type M.2 Card dimension.
    • M.2 Mechanical Key: Key B
    • SIM Connector for CDMA HSDPA/HSUPA,UMTS, GSM, GPRS, EDGE

    System Requirement


  • USB 3.0 port
  • Windows XP, Vista 32/64, Windows 7, Windows 8 Windows 10, or Linux



Notice:
U0903A is M.2 (NGFF) passive adapter. Just only support Socket 2 SSIC-based WWAN M.2 Module (Key B).
U0903A supports WWAN network card with maximum 6W power consumption.



    Web-shop




U0903A has ceased production and sales,
Please purchase the new product UN32A.

U0903A PCBA V2.2
Unit price: USD 65.
U0903A PCBA V2.2
(M.2 Key B LTE Card to USB 3.0 Adapter)
Flat-Head Screw x4
