First Impression
The U0401A adapter is designed for desktop/Embedded system that converts 3G/4G wireless Mini-Card to USB port.
You can insert your USB type minicard such as GSM, HSPA(3.5G), GPS, LTE cards to this adapter then plug to USB port.
As standard SIM card is provided, you can connect to network carrier with SIM card.
|
Function
- USB A Male to desktop or notebook PC
- Supports USB interface of Mini-Cards such as 2G GSM, GPRS, 3G, CDMA, WLAN, WWLAN, HSPA MODEM, GPS, 4G WiMAX, LTE, and Mini-Card to desktop PC
- Support SIM card connector.
- Include Antenna by U.fl/IPX connector.
- Antenna SPEC:
S.W.R.
<= 3.0 @ 780~960 MHz
<=3.5 @ 1710~2170 MHz
Antenna Gain :
+2.0 ± 0.7 dBi @ 880 MHz
+2.0 ± 0.7 dBi @ 1800 MHz
|
|
Specifications
- System Requirements
USB port
Full / Half -Mini Card dimension
- Dimension
80mm X 30mm X 8mm
- Certifiction
RoHS
- Operating Temperature
0 ~ 70℃
|
|
