   PP1142
PCI Express to USB 3.1 Type C Drive Bay Docking System
(3.5 inch Front Panel Form Factor)







Brief Taiwan 1 Taiwan 2 China
Web-shop


    First Impression


PP1142 is USB 3.1 Front Panel slides easily into any standard 3.5-inch drive bay, so in just three simple steps you'll enjoy the benefits of USB 3.1's 10Gbit/s transfer speeds.


        General Feature


  • Bridge PCI Express to USB 3.1
  • Upload firmware through BIOS or external SPI ROM
  • External 20MHz differential crystal
  • Overclock capability on PCI Express bus under asynchronous mode
  • integrate Spread Spectrum controller for PCI Express and USB3.1 interface
  • Integrate two regulators for normal core power supply and suspend core power supply
  • Support driver on Windows 7, Windows 8, and Windows 8.1
  • Support various Linux Kernels

        PCI Express Feature


  • Support PCI Express Gen2x2 or Gen3x1
  • Up to 10Gbps bandwidth performance with low latency
  • Support PCI Express Link power management
  • Compliant with PCI Express Base 3.0 Specification
  • Compliant with PCI Express card Electromechanical 2.0 specification
  • Compliant with PCI Express Mini Card Electromechanical 1.2 specification
  • Compliant with Express Card Standard Revision 2.0
  • Compliant with PCI Bus Power Management Interface Specification Revision 1.2
  • Compliant with PCI Local Bus Specification Revision 3.0
  • Support overclocking capability on PCI Express interface

        USB Feature


  • Support two port of USB3.1
  • Compliant with Universal Serial Bus 3.1 Specification Revision 1.0
  • Compliant with Universal Serial Bus Specification
    Revision 2.0
  • Compliant with eXtensible Host Controller Interface specification Revision 1.1
  • Compliant with USB Attached SCSI Protocol Revision 1.0
  • Support USB3.1 and USB2.0 Link Power Management
  • Support Control, Bulk, Stream, Interrupt, Isochronous transfer type
  • Support independent port power control
  • Support over current detection
  • Support Remote/Wakeup event
  • Backward compatible with Legacy USB function and device
  • Support the Debug port





    Web-shop



PP1142-HP4F
Unit price: USD 190.

PP1142-HP4F
(PCI Express to USB 3.1 Type C Front Drive Bay Docking System) x1
JP0156
(Low profile PCI express bracket) x1
