    U31MR
(Dual mSATA SSD to USB 3.1 TYPE-C RAID Adapter)




Brief Taiwan 1 Taiwan 2 China
Test Report Taiwan 1 Taiwan 2 China
RAID SETTING SOP Taiwan 1 Taiwan 2 China
Buy It Now


First Impression

U31MR is Dual mSATA SSD to USB3.1 Type C adapter design for SATA-IO mSATA SSD mobile solution.

The adapter will allow you to use dual mSATA SSD module through USB 3.1 type C port on your desktop or laptop with RAID function.

        Function

  • Allows user to use standard SATA3 mSATA SSD to USB type C port in the Desktop or Laptop
  • Compatible with Full/Half card dimension size of MINI SATA SSD Module
  • Active LED
  • Support Hi-Speed USB 3.1 (10Gbps), SATA3 (6Gbps) mass storage interface.
  • RAID mode :
    JBOD (Port Multiplier),
    RAID0 (Striping/Fast),
    RAID1(Mirror/Safe),
    Span (Big)



 SW1

GUI

JBOD

RAID1

RAID0

Span

PIN 1

OFF

ON

ON

ON

ON

PIN 2

X

OFF

OFF

ON

ON

PIN 3

X

OFF

ON

OFF

ON

        Operating Temperature

  • 0 ~ 70℃

        Dimension & Weight

  • 143mm X37.79mm X 8.95mm
  • 52.8g

        System Requirement

  • Windows XP, Vista, Windows 7, Windows 8, Window 10, Server 2008, Windows 8,Linux, Mac iOS



Package Content

U31MR
Unit price: USD 180.

U31MR
(Dual mSATA SSD to USB 3.1 TYPE-C RAID Adapter) x1

Y24-U01-050
(USB 3.1 C-type to USB3.0 A-type Cable 50cm) x1

 Y24-U02-050
(USB 3.1 C-type to USB3.1 C-type Cable 50cm) x1
 Y05-U17-060
(USB A Male to DC Power Cable) x1

Heat Sink x1

Flat-Head Screw x4
