   M2P4S
M.2 (NGFF) PCIe base SSD to PCIe X4 Adapter







Brief Taiwan 1 Taiwan 2 China
Buy It Now


First Impression


M2P4S adapter enables dual PCIe base M.2(NGFF) SSD such as Samsung XP941 or Plextor M6e as a HDD Cards for desktop PC.
M2P4S design two slot for M.2(NGFF) SSD:
One M.2 slot use for PCIe x4 slot for desktop PC directly.
Another slot can be connected into another PCIe Slot with P23S gold finger though FFC (Flat Flexible Cable) cable for flexible use.

The module can support system boot.


    Boot from M.2 SSD storage.


We successfully installed the system through M2P4A Samsung SSD, and the success of the boot.
Operating platform follows:
CPU: Intel® Pentium® Processor G3258
MB: ASROCK Z97 Killer
OS: Windows 8.1 64bit
Adapter : M2P4A
SSD Hard Drive: Samsung XP941-128G M.2(NGFF) PCIe x4 SSD

Most Z97 chipset can support boot with PCIe’s storage.
You can simply install the OS but chose the M.2 storage.
The chose setup BIOS to boot from it.


    Note:
    Because z97’s BIOS is UEFI BIOS, make sure you boot from “UEFI: your storage name”.
  • If you use generic’s USB dongle to install your OS, then you need to choose “UEFI: generic storage”.
  • If you use CD ROM to install your OS, please choose “UEFI: WDC WD10EARS-OOMVMBO”

    Boot selection:



    Function


  • Allows user to use two of standard PCIE base M.2 SSD to PCIe x4 in the Desktop or Laptop.
    = Two PCIe x4 Gen3 slots required
  • Design the FFC (Flat Flexible Cable) for flexible use:
    20cm FFC & P23S PCIe X4 Gold Finger
  • Transparent to the operating system and does not require any software drivers.

    Specifications


  • M.2 SSD to PCIe Gen3 X4 adapter.
    maximum 32Gbps
  • M.2 Specification Revision 1.0
  • Support 2230/2242/2260/2280/22110 type M.2 Card dimension.
  • Support M.2 Socket 3 PCI-e-based SSD Module.
  • Support PCIe Gen3 x4
  • Support M.2 Key M Card Type.
    * Note: M.2 Key B/B+M SATA not supported



M.2 SSD to PCI-E from factor Adapter Compatibility List

2013Dec13
Gerry Chen
Brand / Model Function Interface Size M2P4A M2P4S M2PS   Note
Samsung SM951 512GB SSD PCIe key M 2280 Pass Pass NG
Samsung SM951 256GB SSD PCIe key M 2280 Pass Pass NG
Samsung SM951 128GB SSD PCIe key M 2280 Pass Pass NG
Samsung XP941
MZHPU128HCGM-00000
SSD PCIe key M 2280 Pass Pass NG
Samsung XP941
MZHPU256HCGL-00000
SSD PCIe key M 2280 Pass Pass NG
Samsung XP941
MZHPU512HCGL-00000
SSD PCIe key M 2280 Pass Pass NG
Samsung M.2 128G
MZ-NPD1280
SSD SATA key B / M 2280 NG NG Pass
Samsung M.2 128G
MZNTD128HAGM
SSD SATA key B / M 2280 NG NG Pass
BPLUS M2EM SSD SATA key B / M 2242 NG NG Pass
ADATA AXNS341N-64GM-B SSD SATA key B / M 2242 NG NG Pass
Sandisk X110 SSD SATA key B / M 2242 NG NG Pass
Samsung MZNTD128HAGM SSD SATA key B / M 2280 NG NG Pass
Intel
SSD Pro 1500 Series
SSD SATA key B / M 2280
2242
NG NG Pass
Intel
SSD 530 Series
SSD SATA key B / M 2280 NG NG Pass
Tohsiba THNSNHGDNT SSD SATA key B / M 2280 NG NG Pass
LITE-ON L8T-128L6G-HP SSD SATA key B / M 2280 NG NG Pass

Brand Function Interface Size M2P4A M2P4S M2PS   Note
Key M Key M Key B
M2P4A / M2P4S (M.2 Key M)
Designed for PCIE x4 based M.2 (NGFF) SSD module

M2PS (M.2 Key B)
Designed for SATA based M.2 (NGFF) SSD module



Package Content



M2P4S
Unit price: USD 76.

M2P4S
(M.2 PCIe base SSD to PCIe X4 Adapter) x1
Flat-Head Screw x2




M2P4S-P23S
Unit price: USD 100.

M2P4S
(M.2 PCIe base SSD to PCIe X4 Adapter) x1
P23S (KZ-B23x4)
(PCIe X4 Eextender Board) x1
with
FFC0536P-020A x1
FFC0550P-020A x1
Flat-Head Screw x2







P23S
Unit price: USD 30.

P23S (KZ-B23x4)
(PCIe X4 Eextender Board) x1
with
FFC0536P-020A x1
FFC0550P-020A x1
