   M2P4A
PCIe 3.0 X4 to M.2 (NGFF) SSD Adapter







Brief Taiwan 1 Taiwan 2 China
Web-shop


First Impression


M.2 stands for Next Generation Form Factor which is invented for PCI-SIG by Intel and it is developed for flat and high-efficiency equipment such as Ultrabook™ or Tablet PCs. It is a natural transition from the Mini Card and Half Mini Card to a smaller form factor in both size and volume which supports multiple function add-in cards/modules including: Wi-Fi, Bluetooth, global navigation satellite systems, near field communication, Hybrid digital radio, wireless gigabit alliance (WiGig), wireless wide area network and solid-state storage devices. Also adds functionality to USB 3.0, display Port, SDIO and SSD-PCIe


M2P4A adapter enables PCIe base M.2(NGFF) SSD as a HDD Card for desktop PC.
M2P4A design for M.2(NGFF) SSD.

    Function


  • Allows user to use standard PCIE base M.2 SSD to PCIe x4 in the Desktop or Laptop.
  • Transparent to the operating system and does
    not require any software drivers.

    Specifications


  • M.2 SSD to PCIe X4 adapter.
  • M.2 Specification Revision 1.0
  • Support 2230/2242/2260/2280/22110 type M.2 Card dimension.
  • Support M.2 Socket 3 PCI-e-based SSD Module.
  • Support PCIe Gen3 x4
  • Support M.2 Key M Card Type.
  • Heat Sink (92x57x8 mm) for SSD module.

    Boot from M.2 SSD storage.


We successfully installed the system through M2P4A Samsung SSD, and the success of the boot.
Operating platform follows:
CPU: Intel® Pentium® Processor G3258
MB: ASROCK Z97 Killer
OS: Windows 8.1 64bit
Adapter : M2P4A
SSD Hard Drive: Samsung XP941-128G M.2(NGFF) PCIe x4 SSD

Most Z97 chipset can support boot with PCIe’s storage.
You can simply install the OS but chose the M.2 storage.
The chose setup BIOS to boot from it.


    Note:
    Because z97’s BIOS is UEFI BIOS, make sure you boot from “UEFI: your storage name”.
  • If you use generic’s USB dongle to install your OS, then you need to choose “UEFI: generic storage”.
  • If you use CD ROM to install your OS, please choose “UEFI: WDC WD10EARS-OOMVMBO”

    Boot selection:





M.2 SSD to PCI-E from factor Adapter Compatibility List

2013Dec13
Gerry Chen
Brand / Model Function Interface Size M2P4A M2P4S M2PS   Note
Samsung SM951 512GB SSD PCIe key M 2280 Pass Pass NG
Samsung SM951 256GB SSD PCIe key M 2280 Pass Pass NG
Samsung SM951 128GB SSD PCIe key M 2280 Pass Pass NG
Samsung XP941
MZHPU128HCGM-00000
SSD PCIe key M 2280 Pass Pass NG
Samsung XP941
MZHPU256HCGL-00000
SSD PCIe key M 2280 Pass Pass NG
Samsung XP941
MZHPU512HCGL-00000
SSD PCIe key M 2280 Pass Pass NG
Samsung M.2 128G
MZ-NPD1280
SSD SATA key B / M 2280 NG NG Pass
Samsung M.2 128G
MZNTD128HAGM
SSD SATA key B / M 2280 NG NG Pass
BPLUS M2EM SSD SATA key B / M 2242 NG NG Pass
ADATA AXNS341N-64GM-B SSD SATA key B / M 2242 NG NG Pass
Sandisk X110 SSD SATA key B / M 2242 NG NG Pass
Samsung MZNTD128HAGM SSD SATA key B / M 2280 NG NG Pass
Intel
SSD Pro 1500 Series
SSD SATA key B / M 2280
2242
NG NG Pass
Intel
SSD 530 Series
SSD SATA key B / M 2280 NG NG Pass
Tohsiba THNSNHGDNT SSD SATA key B / M 2280 NG NG Pass
LITE-ON L8T-128L6G-HP SSD SATA key B / M 2280 NG NG Pass

Brand Function Interface Size M2P4A M2P4S M2PS   Note
Key M Key M Key B
M2P4A / M2P4S (M.2 Key M)
Designed for PCIE x4 based M.2 (NGFF) SSD module

M2PS (M.2 Key B)
Designed for SATA based M.2 (NGFF) SSD module




All of Model Where to buy? Special Information
M2P4A Web-shop M.2 key M to PCIe passive adapter
M2P4A-S128G Contact Sales PCIe 3.0 x4 128G SSD Card
M2P4A-S256G Contact Sales PCIe 3.0 x4 256G SSD Card
M2P4A-S512G Contact Sales PCIe 3.0 x4 512G SSD Card

    Web-shop



M2P4A
Unit price: USD 100.

M2P4A
(PCIe 3.0 X4 to M.2 SSD Adapter) x1
Flat-Head Screw x1




Buy Related Items


M2P4S
