M2MS1
M.2 (NGFF) to mSATA Adapter

(Socket 2 SATA-based , Key B, Maximum dimension type 3042)

Brief	Taiwan 1	Taiwan 2	China
Web-shop

First Impression

M.2 stands for Next Generation Form Factor which is invented for PCI-SIG by Intel® and it is developed for flat and high-efficiency equipment such as Ultrabook™ or Tablet PCs. It is a natural transition from the Mini Card and Half Mini Card to a smaller form factor in both size and volume which supports multiple function add-in cards/modules including: Wi-Fi, Bluetooth, global navigation satellite systems, near field communication, Hybrid digital radio, wireless gigabit alliance (WiGig), wireless wide area network and solid-state storage devices. Also adds functionality to USB 3.0, display Port, SDIO and SSD-PCIe

Function

Allows user to use M.2 Socket 2 SATA-based Module to mPCIe Slot in the Desktop or Laptop.
Supports Support Hi-Speed SATA3/ 6Gbps mass storage interface.
No drivers needed for this M.2 to mSATA Card Adapter

Specifications

M.2 Specification Revision 0.9-3
Serial ATA Revision 3.1
Support 3030/3042 M.2 Card dimension.
Support M.2 Socket 2 SATA-based Module.
Support M.2 Key B/B+M Card Type.
Support Full size and half size mPCIe slot

System Requirement

mSATA slot
Windows 2000, XP, Vista 32/64, Windows 7, Windows 8 or Linux

M.2 (NGFF) to mini PCI-E Adapter comparison
Model Name	UN32B	M2BU3S-U3D	M2BU3S-U2D	M2BU3S-PU	M2MU2
Function	M.2 to mini card Rev 2.1	M.2 to mini card Rev 2.1	M.2 to mini card Rev 2.1	M.2 to mini card Rev 2.1	M.2 to mPCIe
Interface	PCIe & USB 3.0	USB 3.0	USB 2.0	PCIe 2x or SATA	USB 2.0
M.2 SPEC	Socket 2 PCIe & USB3.0 dual bus WWAN	Socket 2 SSIC-based WWAN	Socket 2 SSIC-based WWAN	Socket 2	Socket 2 SSIC-based WWAN
Application	5G / 4G / 3G / CDMA / LTE / GPS module	4G / 3G / CDMA / LTE / GPS module	4G / 3G / CDMA / LTE / GPS module	PCIe 2x or SATA SSD module	4G / 3G / CDMA / LTE / GPS module
Module KEY	B	B	B	B	B
Support Card Type	3030/3042/3050/3052	2242,50,52 / 3042,50,52	2242,50,52 / 3042,50,52	2242,50,52 / 3042,50,52	2230/2242/3030/3042

M.2 (NGFF) to mini PCI-E Adapter comparison
Model Name	M2MP1-A	M2MP1-E	M2MP3-A	M2MP3-E	M2MS1
Function	M.2 to mPCIe	M.2 to mPCIe	M.2 to mPCIe	M.2 to mPCIe	M.2 to mSATA
Interface	PCIe & USB2.0	PCIe & USB2.0	PCIe & USB2.0	PCIe & USB2.0	SATA
M.2 SPEC	Socket 1 First PCIe Lane	Socket 1 First PCIe Lane	Socket 1 Second PCIe Lane	Socket 1 Second PCIe Lane	Socket 2 SATA-based
Application	WiFi+BT module	WiFi+BT module	WiFi+BT module	WiFi+BT module	SATA SSD module
Module KEY	A	E	A	E	B / B+M
Support Card Type	2230/2242/3030/3042	2230/2242/3030/3042	2230/2242/3030/3042	2230/2242/3030/3042	2230/2242/3030/3042
