    M2S-C
(SATA to M.2-Socket2-B+M-2242-SATA Adapter)





V1.1 Brief Taiwan 1 Taiwan 2 China
V1.0 Brief Taiwan 1 Taiwan 2 China
Buy It Now


First Impression


M2S-C is SATA adapter from M.2 Socket 2. This module allows you connect any SATA device to M.2 slot through a standard SATA port.
M2S supports M.2 socket 2 with TYPE 2242-D2-B-M of SATA SSD. SATA interface supports standard SATA 7pin data signals.

M2S-C is the best solution to evaluate M.2 SATA SSD socket.

    Specifications


  • Standard SATA interface adapter from M.2 Socket 2 slot for SATA SSD
  • Compliant with PCIe M.2 Specification Rev 1.0
  • Body Size: TYPE 2242-D2-B-M
  • Module Key : B+M (Both Key B and Key M)
  • Interface : Standard SATA 7pin Connector
  • Compliant with Serial ATA Revision 3.1

    OS Support


  • Transparent to the operating system and does not require any software drivers.

    System Requirement


  • Type 2242 M.2 Socket 2 with Key B or M for SATA

    Notice


  • This adapter is engineering test tools. NOT for home or office use.
  • Rev 1.0 Compliant. Specification may vary in newer revision.
  • The Products just only support M.2 SATA slot, Can’t support other SSD such as mSATA, Eee PC SSD, Apple MacBook air SSD Card.
  • Support SATA interface only. No other interface (such as PCIe or USB) is supported.

Package Content


M2S-C
Unit price: USD 70.

M2S-C
SATA to M.2-Socket2-B+M-2242-SATA adapter
Flat-Head Screw x1


Buy Related Items


M2S
SSDM2
SSDM2 module
