   S4EX
(SIM Card Extender)


Introduction:
The S4EX SIM Extender is a test and signal detection tool for SIM card. It allows a SIMcard to be extended from the host slot for full access to the all of signal pins.

It’s especially designed to save valuable labor and time in the production environment. The S4EX is designed to minimize the signal degradation effects of the extender by proven design techniques. Separate Vcc and ground planes provide a low inductance path to the host’s power supply.

The SIM (Subscriber Identity Module) extender has the function of over-current protection with PTC fuse. A clearly marked jumper header allows probing of all of signal pins. It’s also a powerful tool for engineers, or use for factory test protection.

        Features


  • Test connector for all of signal and power pins.
  • Any signal can be isolated with test pin.
  • Power and ground can be isolated for power measurements.
  • LED indicates power status.
  • Adds LED enable switch and fuse enable switchs.
  • Vcc bypassed for clean power.
  • Supports both Smartcards and SIM cards.
  • High quality connectors for long service life.
  • Over-current protection with PTC fuse
  • Supports Smartcard Vcc 1.8V, 3V, 5V

         Support Card Type:


  • Mini-SIM ISO/IEC 7810:2003, ID-000 25mmx15mmx0.76mm

        Dimension


  • Width : 32.51mm
  • Length : 65.03mm
  • PCB Thickness 0.8mm



S4EX
Unit price: USD 70.
S4EX (SIM Card Extender) x1


Documents Download
V1.1 Brief   Taiwan   Taiwan 2 Mirror   China Mirror
V1.0 Brief   Taiwan   Taiwan 2 Mirror   China Mirror
