 SDCBA-C01
(SDHC/SD/MMC to CardBus PC Card High Speed Adapter


Introduction:
Proudly presents you a perfect solution for accessing the SDHC (Secure Digital High Capacity) / SD (Secure Digital) / MMC (MultiMediaCard) via 32-bit CardBus interface with a higher speed.
This adapter supports converting SD, SDHC, miniSD (with adapter), microSD (with adapter), microSDHC (with adapter), MMC, RS-MMC (with adapter), MMC Plus, and MMC Mobile (with Adapter) to Type II CardBus PC Card.  A Push-Push socket is equipped for easy insertion/extraction of supported cards.
SDCBA-C01 is also compliant with SDIO specification, which allows you to use SDIO card with all kinds of applications on your computer.
SDCBA-C01 is a very convenient and high speed SDHC/SD/MMC card adapter/reader for any computer equipped with 32-bit CardBus socket.  If you are tired of using the card reader with a slow speed, you should absolutely try SDCBA-C01.

    Features

  • Compliant with 32-bit CardBus Type II PC Card interface (JEIDA 4.2).  Maximum frequency reaches 33MHz.
  • Compliant with SD Memory Card Specification 2.0.
  • Supports SDHC / High Speed SD Clock (50MHz)
  • Compliant with SDIO Specification 1.1
  • Supports all kinds of SDIO Card Applications.
  • Compliant with SD Host Controller Standard Specification 1.0
  • Compliant with MultiMediaCard Specification 4.1
  • Supports MMC Plus and MMC Mobile (with adapter.)
  • Push-Push card slot for easy insertion/extraction of card.
  • Low power consumption, 3.3V single power operation.
  • Software Suspend mode compliant with ACPI.
  • Supports Hardware Suspend.

Specifications


Input Socket SDHC / SD (SD Specification 2.0)
  SDIO (SDIO Specification 1.1)
  MMC (MMC Specification 4.1)
Output Interface 32-bit CardBus Type II PC Card
Supporting Card SDHC 4GB
  SD 8MB~2GB
  miniSD 8MB~2GB (Adapter Required)
  microSDHC 4GB~ (Adapter Required)
  microSD 8MB~2GB (Adapter Required)
  MMC / MMC Plus All Capacities
  RS-MMC / MMC Mobile All Capacities
Supporting OS Windows XP / VISTA
Safety Approval CE / FCC
Dimensions 85.0 mm(L)* 54.0 mm(W)* 5.0 mm(H)


Application Diagram


SDCBA-C01
Unit price: USD 45.
SDCBA-C01
(SDHC/SD/MMC to CardBus PC Card High Speed Adapter) x1


Documents Download
Brief(PDF):  Taiwan 1   Taiwan 2 Mirror   China Mirror
SD cardreader comparison  Taiwan 1  Taiwan 2 Mirror  China Mirror
