   U3M2B
M.2 SATA SSD to USB3.0 Adapter




Brief Taiwan 1 Taiwan 2 China
Web-shop


First Impression

U3M2B is M.2 SATA SSD to USB3.0 adapter design for PCI-SIG M.2 SATA SSD mobile solution. This adapter is allow to use M.2 SATA SSD 2242 / 2260 / 2280 module with KeyB or B+M through USB3.0 port on your desktop or laptop.

DevSlp (Device Sleep) is supported to save power consumption especially in idle mode.



Performance:
mSATA SSD: Plextor PX128M-5M 128GB
OS: Window8.1

Power Save:
DevSlp (Device Sleep): < 10mA



No DevSlp (No Device Sleep): 160mA


* When just connected to USB3.0 port and no data transaction in idle mode







        Function

  • Allows user to use standard SATA3 M.2 SATA SSD to USB3.0 port in the Desktop or Laptop
  • Compatible with 2240, 2260, 2280 (XXYY: XXmm width, YYmm length) dimension size of M.2 SATA SSD Module with KeyB or KeyB+M.
  • Active LED
  • Support Hi-Speed USB 3.0(5Gbps), SATA3(6Gbps) mass storage interface.
  • DevSlp (Device Sleep) Supported

        Dimension & Weight

  • 98.5mm X 37.5mm X 10m  ; 23.5g (No SSD included)

        System Requirements

  • Windows XP/Vista/7/8/8.1/Server 2008, Linux, Mac iOS

        Certification

  • RoHS

        Operating Temperature

  • 0 ~ 70℃





    Web-shop


U3M2B
Unit price: USD 100.

U3M2B
 (M.2 SATA SSD to USB3.0 Adapter) x1
Enclosure color: Silver
Y09-U09-045
(USB 3.0 A Male to Micro B Male 45cm Cable) x1

Flat-Head Screw x2





U3M2B-R
Unit price: USD 100.

U3M2B-R
(M.2 SATA SSD to USB3.0 Adapter) x1
Enclosure color: Red
Y09-U09-045
(USB 3.0 A Male to Micro B Male 45cm Cable) x1

Flat-Head Screw x2
