    PP1061
(mSATA to PCIe x1 Adapter)





Brief V1.1 Taiwan 1 Taiwan 2 China
Brief V1.0 Taiwan 1 Taiwan 2 China
Driver Taiwan 1 Taiwan 2 China
Buy It Now


First Impression


The mSATA to PCIe adapter is a converter tool for PCI-E interface.
This module allows you connect 2 mSATA SSD to the PCI Express slot.
The module can support system boot.

    Function


  • Use ASM1061 single chip, 1-lane PCI Express to 2-port Serial ATA III Host Controller.
  • Support Native Command Queuing (NCQ)
  • Support port Multiplier
  • Support system boot

    OS Support


  • AHCI standard inbox driver (eg. Windows, Linux OS)

    Compliance


  • Compliant with Serial ATA AHCI (Advanced Host Controller Interface) Spec. Reversion 1.3
  • Compliant with PCI Express Base Spec. Revision 2.0, Supports 1-Lane 5.0Gbps
  • Compliant with Gen 1i, Gen 1x, Gen 2i, Gen 2m, Gen 2x, and Gen 3i Serial ATA III: Electrical Spec. Revision
  • Supports 2-port 6.0Gbps SATA III interface

    Notice


  • The Product just only support 2 mSATA slot, Can’t support mPCIe device module, otherwise it can’t work.
  • The adapter can provide additonal power supply from SATA power cable, but the default is using the power from PCIe gold finger, it is enough.

Package Content


PP1061
Unit price: USD 80.
PP1061
(mSATA to PCIe x1 Adapter) x1
JP0155
( Standard Height PCI express bracket ) x1
Screw x4
