   PM4F-Ux
mini card to PCIe Adapter







Web-shop

    First Impression


The PCI-E Mini Card passive adapter is designed for wireless application on desktop PCs that convert Mini-Card to USB port or standard PCI-Express 1x slot.
You can insert your USB 3.0 or USB 2.0 type minicard to this adapter then plug to USB port through USB cable.
Or insert your PCI-E type mini-card into this adapter then insert to PCI-E 1x connector.



       PM4F-Ux Feature


  • PCI Express Mini Card to PCI express 1x converter.
  • Allows user to test PCI Express Mini modules on the PCI Express slot.
  • Supports two primary system bus interface: PCI Express and USB3.0 USB 2.0.
  • Supports all of Mini-Cards such as 3G,CDMA, WLAN,WWLAN,LTE, Mini Card to desktop PC.
  • PM4F-U3F Support Dual SIM Card.
  • Supports U.FL/IPX to SMA pigtail Wireless RF cable adapter.
  • Supports U.FL/IPX to RP- SMA pigtail Wireless RF cable adapter.







    PM4F-Ux Specification


  • PM4F-U3F : PCI Express Mini Card to PCI Express / USB 3.0 adapter.
  • PM4F-U2F : PCI Express Mini Card to PCI Express / USB 2.0 adapter.
  • PCI Express Mini Card Electromechanical Specification Revision 1.0
  • PCI Express Card Electromechanical Specification 1.1
  • PM4F-U3F : Universal Serial Bus Specification Revision 3.0.
    PM4F-U2F : Universal Serial Bus Specification Revision 2.0.
  • Standard Height PCI Express Add-in Card
  • Low Profile PCI Express Add-in Card.
  • Full / Half -Mini Card dimension.



    Notice


  • There are existing mPCIe 'form factor' SSD's that present SATA and PATA interface, but none that use the standard mPCIe pinout (i.e. mPCIe tx/rx pins). ...
  • PM4F-Ux support standard mPCIe minicard.
    Can’t support custom SATA/PATA SSD minicard.






Web-shop




PM4F-U3F V12
Unit price: USD 80.

PM4F-U3F V12
(mini card Rev 2.1 to PCIe Adapter) x1
with RF11005A x3
RF11005A
( IPX to SMA cable 5cm)
Screw x4


95Q16011191QM01
( 9Pin 1.5 Pitch Header to Type A USB3.0 cable 60cm) x1



PM4F-U2F
Unit price: USD 65.

PM4F-U2F
(mini card to PCIe Adapter) x1
with RF11005A x3
RF11005A
( IPX to SMA cable 5cm)
Screw x4

Y05-U02-060
(USB Dupont to 5PIN Cable) x1
