Home > Product > Extender Module > PM2H

  PM2H
(PCI-E to Half / Full Mini PCI-E Adapter)







Brief Taiwan 1 Taiwan 2 China
Buy It Now


First Impression


The PCI-E 1x to half Mini PCI-E Card is a debug tool for PCI-E interface card.
This module allows you to use your existing PCI-Express Add-in-Card in both half and full size Mini PCI-E slot.
It's especially designed to save valuable labor and time in the production environment.
As a powerful tool for engineers, the PCI-E 1x to half / full Mini PCI-E Card is constructed of high quality components for years of trouble free service.



      Function


  • Support both half and full size Mini PCI-E slot.
  • Designed to meet PCI Express™ Mini Card Electromechanical
    Specification Revision 1.0 and PCI Express™ base specification
    vision 1.1
  • Supports 1x PCI-Express Card and USB
  • Compliant with multi-system of PC
  • High quality connectors for long service life
  • Use external 5V/12V power supply for USB and PCIe device

      System Requirement


  • PCI Express mini card slot : Half or Full Size

       Dimension


  • Width 30mm, Length 26mm, PCB Thickness 1.0mm Max

       Certification


  • RoHs



    Package Content


PM2H
Unit price: USD 50.

PM2H
(PCI-E to Half / Full Mini PCI-E Adapter) x1
with Metal Baffle x1
Y04-V01-015
(External 5V/12V power supply) x1
Screw x4






    Buy Related Items


PM2
PM2C
