First Impression
The PE4C v1.2 is designed for Notebook PCs that converts PCI Express 16X Add-on Card to ExCard or
mPCIe connecter.
This adapter allows you to use your existing PCI-E 16X Card in the notebook PC for test
|
|
Specification
- PE4C-PM3E V1.2 allows user to test PCI Express x16 Add-in-Card on the PCI Express mini card (mPCIe) slot.
- PE4C-EC3C V1.2 allows user to test PCI Express x16 Add-in-Card on the ExpressCard slot
- Compliant with PCI Express 2.0 Specification: Maximum 5Gbps
- Compliant with USB2.0 Specification: Maximum 480Mbps
- Power Supply: ATX PSU, directly connect to 24pin connector.
System Requirements
- Windows XP/Vista/7/8/8.1/Server 2008, Linux, Mac iOS
|
|
Dimension & Weight
- 11cm X 4.5cm X 1.5cm ; 23.5g
Operating Temperature
- 0 ~ 70℃
|
|
Notice
- PE4C V1.2 is PCIe 1-Lane 5.0Gbps bandwidth limit passive adapter in compliance with Expresscard 2.0 specification
- Basically, PCIe add-on card designed for desktop. We can’t guarantee it compatibility with your laptop. Depends on OS version, notebook’s BIOS, device driver,
- Almost PCIe 16x video card can’t get enough memory resource are allocated. Can’t work in your laptop.
- External Power ATX Power required.
- All of interoperability is not guaranteed.
|
Package Content
PE4C-EC3C V1.2
Unit price: USD 100. |
|
|
|
|
PE4C V1.2 x1
 |
EC3C x1
 |
FFC0516P-010A (FFC cable 10cm) x1
FFC0516P-030A (FFC cable 30cm) x1
FFC0516P-060A (FFC cable 60cm) x1
 |
PE4C-PM3E V1.2
Unit price: USD 90. |
|
|
|
|
PE4C V1.2 x1
|
PM3E x1
 |
FFC0516P-010A (FFC cable 10cm) x1
FFC0516P-030A (FFC cable 30cm) x1
FFC0516P-060A (FFC cable 60cm) x1
|
PE4C-HP3A V1.2
Unit price: USD 90. |
|
|
|
|
PE4C V1.2 x1
|
HP3A x1
 |
FFC0516P-010A (FFC cable 10cm) x1
FFC0516P-030A (FFC cable 30cm) x1
FFC0516P-060A (FFC cable 60cm) x1
|
|
