   PE3B
(Mini Card to ExpressCard Adapter)

Introduction:
This PE3B passive adapter allows you to use your existing PCI express mini-Card in the ExpressCard Standard slot
Add SIM socket for 3G minicard and add DC jack for external power source.

    Specification:

  • Express Card Standard Release 1.0 (PCMCIA)
  • PCI Express base Specification 1.0
  • PCI Express Mini Card Electromechanical Specification Revision 1.2
  • Universal Serial Bus Specification Revision 2.0
  • Ready for Full / Half -Mini Card dimension.
  • SIM Connector for CDMA HSDPA/HSUPA, UMTS, GSM, GPRS, EDGE minicard.
  • Access LED; Power LED; PERST# LED.
  • USB2.0 and PCI-E minicard support.
  • PTC fuses and power switch for power protection.


System Requirements:

ExpressCard Standard Release 1.0 slot



PE3B
Unit price: USD 130.

PE3B
( Mini Card to ExpressCard Adapter ) x1
 Screw x2


Buy Related Items

Antenna
IPX cable



Documents Download
Brief  Taiwan  Taiwan 2  China Mirror
