   MS2M
mSATA SSD to SATA RAID Adapter




Brief Taiwan 1 Taiwan 2 China
Web-shop




        Function

  • Allows user to use standard SATA-IO mSATA SSD to SATA hard drive in the Desktop.
  • Support Hi-Speed SATA3 / 6Gbps mass storage interface.
  • Support software RAID 0/1/5/10.
  • Support OS RAID and Mother-Board RAID 0/1/5/10.
  • PCB board can be stacking.

        Specifications

  • Serial ATA Spec. Reversion 3.2
  • Compatible with Full/Half card dimension size of MINI SATA SSD Module.





        System Requirements

  • Desktop PC with an available SATA slot.
  • Available PCIe slot/2.5” hard drive space/3.5”hard drive space.
  • Windows, Vista 32/64, Windows 7, Windows 8, Windows 10 Windows server 2008/2010/2012 or Linux.

        Certification

  • RoHs

        Operating Temperature

  • 0 ~ 70℃

    Web-shop


MS2M-CT45
Unit price: USD 110.
MS2M-CT45
(Quad mSATA SSD to SATA RAID Adapter) x1
 Y07-S04-040
(SATA3 cable 40cm) x4
 Y15-V03-015
(15 Pin SATA Male to 2 IDE Splitter Female Power Cable 15cm) x2
 Screw x8
CT45 Accessory Screw Kit x1



MS2M-CT43
Unit price: USD 110.
MS2M-CT43
(Quad mSATA to SATA RAID Adapter) x1
 Y07-S04-040
(SATA3 cable 40cm) x4
 Y15-V03-015
(15 Pin SATA Male to 2 IDE Splitter Female Power Cable 15cm) x2
 Screw x8
CT43 Screw x8



MS2M-4
Unit price: USD 90.
MS2M-4
(Quad mSATA to SATA RAID Adapter) x1
 Y07-S04-040
(SATA3 cable 40cm) x4
 Y15-V03-015
(15 Pin SATA Male to 2 IDE Splitter Female Power Cable 15cm) x2
 JP0155
(Standard Height PCI express bracket) x1
Screw x8



MS2M-2
Unit price: USD 60.
MS2M-2
(Dual mSATA to SATA RAID Adapter) x1
 Y07-S04-040
(SATA3 cable 40cm) x2
 Y15-V03-015
(15 Pin SATA Male to 2 IDE Splitter Female Power Cable 15cm) x1
 JP0155
(Standard Height PCI express bracket) x1
Screw x4
