    MP2S
(mPCIe SSD to PATA / SATA adapter ver1.0b)




Introduction:
MP2S is passive adapter design for Desktop SSD solution. that converts custom mPCIe SSD to SATA/PATA connector on main-board.
The adapter will allow you to use mPCIe SSD card as a hard drive on your PATA/SATA motherboard.

MP2S


    Features

  • allows user to use custom mPCIe SSD to PATA/SATA connector in the Desktop.
  • Compatible with MINI PCI-E SSD Module of ASUS EEEPC.
  • Support SATA and PATA interface.
  • Power LED. PATA active LED.



Notice:
The SSD module is controlled via the PATA or SATA interface to the main-board. And not the PCIE bus or USB port. It only requires power from the PCIE bus or USB port or Floppy connector. As a result PCIE/USB connector existing nets on the PCB which are power connecting only.
Almost mPCIe SSD just only  support master mode. So please setting your another IDE device on slave mode if you have. Such as HDD/CD-ROM.

Please check compatibility list for detail.


MP2S
Unit price: USD 30.

MP2S
(mPCIe to PATA / SATA adapter ver1.0b) x1
Y04-V01-015
(External 5V/12V power supply) x1
PATA 80pin cable x1 Y07-S04-040
(SATA3 cable 40cm) x1
JP0155
( Standard Height PCI express bracket ) x1
Screw x2

Notice

The Products only support Eee PC SSD Card(mPCIe SSD Card) ,Can't support mSATA SSD Card and Apple macbook air SSD Card.
Please check compatibility list for detail.


    System Requirements

  • Windows 2000, XP, Vista,Windows 7, Server 2008
  • Linux


MP2S transmission performance test report

Test platform description Mother board: ASUS M2NPV-VM
CPU: AMD Athton 64 X2 Dual core Procossor 3800+ 2.00GHz      RAM: 1.98GB
OS: Windows XP SP3                           Test tool: CrystalDiskMark2.2
Card  Driver test size  read/write performance (Unit : MByte/sec)
Kingspec PATA_8GB Microsoft 5.1.25350 100MB 76.42/24.80
Kingspec SATA_8GB Microsoft 5.1.25350 100MB 92.55/25.92
Silicon POWER SSD PATA_16GB Microsoft 5.1.25350 100MB 37.96/13.58
Kingspec PATA_32GB Microsoft 5.1.25350 100MB 74.81/34.44
Kingspec PATA_64GB Microsoft 5.1.25350 100MB 81.45/45.75


MP2S, SSDMA, SSDMB,SSDMC,SSDMC-U for SSD minicard comparison                2011/Apr/21
Functions comparison
MP2S ver 1.0b
SSDMA
SSDMB
SSDMC
SSDMC-U
Interface
PATA / SATA
USB2.0
USB3.0
SATA
SATA
EeePC PATA SSD minicard support
Yes
Yes
No
No
No
EeePC SATA SSD minicard support
Yes
Yes
No
No
No
mini-SATA SSD minicard support
No
No
Yes
Yes
Yes
Access LED
Yes
Yes
Yes
No
No
Appearance
Add-on card
Enclosure
Enclosure
2.5”HDD
Add-on card
2.5”HDD
Add-on card
Mini USB2.0 connector
MiniCard dimension support
Full/Custom
Full
Full
Full
Full

Notice:
Almost mini-SATA SSD haven’t USB interface. Please check your mini-SATA SSD is supported for USB interface. Otherwise SSDMC-U USB function should invalid.



Documents Download
Brief (PDF):  Taiwan 1   Taiwan 2 Mirror   China Mirror
