EC25858 ( DVR ExpressCard )
H.264 software compression


Introduction:
The EC25858 is an 8-Ch Video and 2-Ch Audio decoder with ExpressCard /34 (PCIe) interface. The EC25858 contains eight high quality NTSC/PAL video decoders with 10-bit A/Ds. And 5-line comb filtering surveillance DVRs that utilize a Windows operating system.



    Specification:

  • Chipset adopt: Conexant CX25858 Audio/Video Decoder with Integrated PCIe Interface
  • Video Input: 8 channels
  • Audio Input: 2 channels
  • Slot: ExpressCard (PCI express interface)
  • Image Quality: 10 bits ADCs super high quality
  • Image Compression: H.264 / MPEG - 4
  • Display Rate: 200fps
  • Compression Ratio: CIF:10-200 M/H/C D1:40-640 M/H/C
  • Record Mode: Continuous recording, Motion recording, Alarm recording
  • Playback: Intelligent search, multi-channel playback
  • Backup: Network remote backup, VCD, AVI, EXE backup
  • Video File Format: AVI
  • Network Protocol: TCP/UDP


System Requirements:

Notebook PC with ExpressCard slot
Windows XP/Windows Vista / 7 32bit Operating System
CPU:Intel Video chipset:Intel,ATI,nVIDIA



EC25858 Software Download

  Windows x32   Windows x32 Multi
  Windows x64   Windows x64 Multi
  GraphEdit - DirectShow Graph Tool
  Linux

EC25858
Unit price: USD 85.
EC25858
( DVR ExpressCard ) H.264 software compression x1
Y10-H01-030
(8-Ch Video 2-Ch Audio Cable) x1

E2EXC-1AG
Unit price: USD 56.
E2EXC-1AG
(ExpressCard 34 to PCIe / USB Adapter) x1
Y04-U04-052
(Dupont 4PIN to 4PIN USB cable) x1



Documents Download

Brief (PDF):  Taiwan  Taiwan 2  China Mirror
User manual(PDF)  Taiwan  Taiwan 2  China Mirror


Software Download

Windows x32  Taiwan  Taiwan 2  China Mirror
Windows x32 Multi  Taiwan  Taiwan 2  China Mirror
Windows x64  Taiwan  Taiwan 2  China Mirror
Windows x64 Multi  Taiwan  Taiwan 2  China Mirror
GraphEdit  Taiwan  Taiwan 2  China Mirror
Linux  Taiwan  Taiwan 2  China Mirror
