    DB8605
(PCI-E Express Gen2 3Lanes, 3port Adapter)


Introduction:
DB8605 is converter tool for PCI-E interface; it is easy and fast for installation.
This module is also allows you to connect 3 PCIe expansion adapters, also add PCI Express slots via flat flexible cable (FFC).
As PCI Express x1 connector is edge-free / multi-lane, x4, x8 and x16 PCIe Cards are also available.

You do not need to plug different PCI-e cards, DB8605 is easy and convenient to use.

    Function

  • Use PLX single chip (PEX 8605), 1-lane PCI Express to 3-port 1-lane PCIe GEN2 Controller.
  • Fully Non-Bolocking Switch architecture.
  • Configurable with serial EEPROM or I2C
  • Design the FFC (Flat Flexible Cable) cable for flexible use.
  • As PCI Express x1 connector is edge-free / multi-lane, x4, x8 and x16 PCIe Cards are also available.

    Specification

  • Compliant with PCI Express Base Spec.Revision 1.1 and 2.0
  • Compliant with PCI Bus Power Management Interface Spec.Revision 1.2
  • Supports all 3-port Gen2 PCIe interface if Gen2 input
  • Power Supply: 3.3V/12V From SATA 15 pin
  •



Web Shop



P21S-DB8605
Unit price: USD 180.
DB8605
(PCI-E Express Gen2 3Lanes, 3port Adapter) x1
P21S x1
FFC0536P-010B x1
FFC0536P-020B x1
FFC0536P-030B x1



Buy Related Items


PP3380
USB3380-EVB
USB3380-AB EVK
USB3380-AB EVK-RC



Documents Download
Brief  Taiwan 1   Taiwan 2 Mirror   China Mirror
