CB242A (PCMCIA Card to PCI Express Adapter)


Introduction:
CB242A is PCI Express to PC Card/PCMCIA adapter. PC card can be used in PCIe slot of desktop PC.
Both 32bit/CardBus Card and 16bit/R2 Card are supported.
Ricoh R5U242 PC Card controller can provide high compatibility and high performance.
As eject bar is available, it is very easy to eject PC Card.
LED PC Card Active LED and Power LED.
Best solution for desktop PC to increase PC Card slot.



    Key Features:

  • PCI Express – PC Card: 32bit/CardBus& 16bit R2/PCMCIA
    Allow users to use PC Card at any PCI Express slot such as on desktop PC
  • Plug & Play Support
  • R5U242: High Performance & Compatibility
    PCI Express: max 2.5Gpbs, CardBus: 133MB/s
  • Large Power Supply for PC Card: 3.3V & 5.0V / 1A
  • Eject bar supported: Easy to remove PC Card
  • LED: PC Card Power LED & PC Card Active LED on Bracket

    Specification:

  • PCI Express Base Specification Rev 1.1 Compliant: max 2.5Gbps
  • PC Card Standard Release 8.1 Specification Compliant
    32bit/CardBus: High Performance: max 133MB/s
    16bit/R2: i82365SL/ExCA Compliant, Compact Flash PC Card mode Support

    System Requirements:

  • Any PCI Express slot (x1, x4, x8, x16)

  • *Design may be changed without notice.
  • *Not all of compatibility is guaranteed


CB242A PCBA
Unit price: USD 60.
CB242A PCBA
(PCMCIA Card to PCI Express Adapter) x1
Notice: without PCI express bracket.
