Intel® Dual Band Wireless-AC 8265
4rd Generation Intel 802.11ac, Dual Band, 2x2 Wi-Fi + Bluetooth* 4.2


Intel® Dual Band Wireless-AC 8265

Ultra Wi-Fi. Ultra Features. Ultra Connected Experience

The Intel® Dual Band Wireless-AC 8265 adapter supports Bluetooth* 4.2 and 2x2
11ac Wi-Fi delivering up to 867Mbps1 including wave 2 features such as downlink
MU-MIMO providing up to 3x increase in user speeds in dense deployments,
supporting fast downloads and long battery life compared to legacy 11ac devices2.
Combined with Intel® Core™ processors and exceptional Intel wireless innovations,
the Intel® Dual Band Wireless-AC 8265 dramatically reshapes your connected
experience at home, work or on the go.

  • 8265NGW
Product Name Intel® Dual Band Wireless-AC 8265
Model Name 8265NGW
Version M.2 (NGFF)
Product Picture
產品圖像
製品画像
Price
價格
価格
USD 20.
Related Items
相 關 配 件
RF22008B
MHF4-RPSMA cable 8cm
US$ 3.
RF12008B
MHF4-SMA cable 8cm
US$ 3.



    4rd Generation Intel 802.11ac Wireless

Faster Speed
Better Coverage
Larger Capacity
802.11ac, Dual Band, 80MHz, 2x2, MU-MIMO
Delivers up to 3x faster Wi-Fi speeds (up to 867 Mbps) than 802.11n, with up to 3x more bandwidth
per stream for more users and devices3. Downlink MU-MIMO allows an Access Point to
simultaneously transmit data to multiple clients and can improve overall downlink network capacity
by up to 3x2. Intel® Wireless-AC enables smoother streaming of higher resolution videos, fewer
dropped connections and less congestion, and faster speed further away from the router.
Bluetooth* 4.2 Dual mode Bluetooth* 4.2 enables BR/EDR-low energy devices to act as a hub and peripheral at the
same time. Connects to the newest low energy Bluetooth* products as well as your familiar devices,
such as headsets, keyboard, mice and more.
Microsoft Windows 10* Ready
Full support for latest Microsoft Windows 10* OS.
M.2 2230 or M.2 1216 Form Factors Multiple form-factors, including M.2 2230 and M.2 1216 modules enable system configuration and
platform usages flexibility. The M.2 1216 form factor delivers 70% smaller footprint and lower profile
optimized for thin-and-light designs4.


   Experience the Intel Difference

Worldwide Regulatory Support
Intel® Dynamic Regulatory Solution
Enables worldwide regulatory compliance on a single Intel® Wireless-AC adapter SKU. The Intel® Dual
Band Wireless-AC 8265 detects its location and automatically optimizes the Wi-Fi settings to local
regulatory requirements, simplifying travel experience and global enterprise procurement. Future
regulatory changes are easily managed during the product lifecycle.


    Business-Class Wireless

Intel® vPro™ Technology5 Supports Intel’s hardware-based security and management features built into Intel® Core™ vPro™
processors and chipsets that enables IT to manage PCs virtually anywhere, anytime while reducing
deployment costs, improving security and ROI.
Intel® Active Management
Technology6
Using integrated platform capabilities and popular third-party management and security applications,
Intel® AMT allows IT or managed service providers to better discover, repair, and protect their
networked computing assets. Intel® AMT is a feature of Intel® Core™ processors with Intel® vPro™
technology.
Intel® PROSet/Wireless Software7 Includes advanced IT tools to improve security, reduce complexity and save IT time and money.
Streamlines client deployments and allows remote management of wireless settings and profiles by
IT managers.



    Intel® Dual Band Wireless-AC 8265 Technical Specifications

General

Dimensions (H x W x D)
Weight
Antenna Diversity
Radio ON/OFF Control
Connector interface
Operating Temperature (Adapter Shield)
Humidity Non-Operating
Operating Systems

Wi-Fi Alliance




Roaming8
Bluetooth*
M.2 2230: 22 mm x 30 mm x 2.4 mm [1.5mm Max (Top Side)/ 0.1mm Max (Bottom Side)]
M.2 2230: 2.6g
Supported
Supported
M.2: PCIe, USB
0º to +80° C
50% to 90% RH non-condensing (at temperatures of 25°C to 35°C)
Microsoft Windows 7*, Microsoft Windows 8.1*, Microsoft Windows 10*, Linux* (limited feature support)
Wi-Fi CERTIFIED* a/b/g/n/ac, WMM*, WMM-PS*, WPA*, WPA2*, WPS2*, Protected Management Frames,
Wi-Fi Direct* for peer to peer device connections, Wi-Fi Miracast* as Source.
IEEE WLAN Standard IEEE 802.11a/b/g/n/ac, 802.11d, 802.11e, 802.11h, 802.11i, 802.11w; 802.11r, 802.11k, 802.11v pending
OS support; Fine Timing Measurement based on 802.11REVmc

Supports seamless roaming between access points
Dual Mode Bluetooth* 4.2, BLE


Security9

Authentication
Authentication Protocols
Encryption
Wi-Fi Direct* Encryption and Authentication
WPA and WPA2, 802.1X (EAP-TLS, TTLS, PEAP, LEAP, EAP-FAST), EAP-SIM, EAP-AKA, EAP-AKA’
PAP, CHAP, TLS, GTC, MS-CHAP*, MS-CHAPv2
64-bit and 128-bit WEP, 128-bit AES-CCMP
WPA2-PSK, AES-CCMP


Compliance

Regulatory
US Government
Product Safety
For a list of country approvals, please contact your local Intel representatives.
FIPS10 ,FISMA
UL, C-UL, CB (IEC 60950-1)

Product Name Model Number Version
Intel® Dual Band Wireless-AC 8265 8265NGW 802.11ac, 2x2, Bluetooth* 4.2, PCIe, USB, M.2 2230 MS
Intel® Dual Band Wireless-AC 8265 8265NGWH 802.11ac, 2x2, Bluetooth* 4.2, PCIe, USB, LTE Coexistence, eFEM, M.2 2230 HE

  1. Based on the theoretical maximum bandwidth enabled by 2x2 802.11ac implementations. Actual wireless throughput and/or range will vary depending on your specific operating system, hardware and software configurations. Check with your device manufacturer for details.
  2. 802.11ac downlink MU-MIMO technology allows concurrently serving multiple devices simultaneously, in turn increasing network capacity by up to 3x while improving per-user throughput.
  3. Compared to 802.11n 40MHz channels, 802.11ac 80MHz provides 3x more bandwidth per stream (Max data rate for 2x2 802.11n 40MHz channel is 300Mbps, 150Mbps per stream; Max data rate for 2x2 802.11ac 80MHz channel is 867Mbps, 433Mbps per stream).
  4. Compared to the footprint of an M.2 2230 module. An M.2 1216 module is 192mm2 (12mmx16mm), approximately 70% smaller than the footprint of a M.2 2230 module (22mmx30mm = 660mm2)
  5. Intel® vPro™ Technology is sophisticated and requires setup and activation. Availability of features and results will depend upon the setup and configuration of your hardware, software and IT environment. To learn more visit: http://www.intel.com/technology/vpro
  6. Requires activation and a system with a corporate network connection, an Intel® AMT-enabled chipset, network hardware and software. For notebooks, Intel® AMT may be unavailable or limited over a host OS-based VPN, when connecting wirelessly, on battery power, sleeping, hibernating or powered off. Results dependent upon hardware, setup & configuration. For more information, visit http://www.intel.com/technology/platform-technology/intel-amt
  7. Intel® PROSet/Wireless Software may not be supported by your device manufacturer. Check with your device manufacturer for details on availability.
  8. Roaming is supported only within each respective band and mode of access points.
  9. Some security solutions may not be supported by your device operating system and/or by your device manufacturer. Check with your device manufacturer for details on availability.
  10. Microsoft Windows 7*, Microsoft Windows 8.1* and Microsoft Windows 10*.

Copyright© 2016 Intel Corporation. All rights reserved.
