Home > Product > Wireless Network Card > Intel® Dual Band Wireless-AC 7265

Intel® Dual Band Wireless-AC 7265


Intel® Dual Band Wireless-AC 7265
802.11ac, Dual Band, 2x2 Wi-Fi + Bluetooth 4.0*

Ultra Wi-Fi. Ultra Features. Ultra Connected Experience

The Intel® Dual Band Wireless-AC 7265 802.11ac, dual band, 2x2 Wi-Fi + Bluetooth® adapter lets you move at the speed of life with
faster speeds (up to 867 Mbps1), higher capacity, broader coverage and longer battery life. Combined with 5th Gen Intel ® Core™ processors
and exceptional Intel wireless innovations, the Intel® Dual Band Wireless-AC 7265 dramatically reshapes your connected experience at home,
work or on the go.

  • 7265NGW
Product Name Intel® Dual Band Wireless-AC 7265
Model Name 7265NGW
Version M.2 (NGFF)
Product Picture
產品圖像
製品画像
Price
價格
価格
USD 29.
Related Items
相 關 配 件
RF22008B
MHF4-RPSMA cable 8cm
US$ 3.
RF12008B
MHF4-SMA cable 8cm
US$ 3.



M2MP1-E-7265
Unit price: USD 73.
M2MP1-E
M.2 (NGFF) to mPCIe (PCIe+USB) Adapter x1
7265NGW
(Intel® Dual Band Wireless-AC 7265) x1
Screw x2
Flat-Head Screw x1





    Next-Gen 802.11ac Wireless

More Speed Better Coverage Larger Capacity 802.11ac, Dual Band, 80MHz, 2x2 Delivers up to 3x faster Wi-Fi speeds (up to 867 Mbps1) than 802.11n, with more bandwidth per stream
433 Mbps), more capacity for more users, broader coverage and better battery life (more data transmit
efficiencies reduce power consumption). Advanced optional 802.11ac specification features
implemented that improve channel reliability resulting in better coverage and performance.
Bluetooth 4.0* Smart Ready (Low Energy) Dual mode Bluetooth® 4.0 connects to the newest low energy Bluetooth® products as well as your
familiar devices, such as headsets, keyboard, mice and more.
Microsoft InstantGo*2 Support
Maintains network connectivity with very low power consumption to enable updates to your
email, social networks, etc. when your screen is off in standby mode.
M.2 2230 and M.2 1216
Form Factors
Multiple form-factors, including M.2 2230 and M.2 1216 modules enable system
configuration and platform usages flexibility. The M.2 1216 form factor delivers 70%
smaller footprint and lower profile optimized for thin-and-light designs.


    Experience the Intel Difference

Your Ultrabook™ , On Your TV
Intel® Wireless Display3
Watch your PC or Ultrabook™ content instantly without wires on the big HD screen with stunning
image clarity and sound. Intel® Wireless Display gives you a serious entertainment upgrade.
Stream movies, videos, games, photos, connect with friends, and more—experience it all, bigger
and better than ever before.
Always Ready to Go
Intel® Smart Connect Technology4
Stay current with automatic, no-wait updates to your email and social networks, even when your
device is asleep. Combine it with Intel® WiFi HotSpot Assistant and automatically connect to
millions of free and paid hotspots to refresh your content in more locations worldwide.
Instant Internet Worldwide
Intel® WiFi Hotspot Assistant6
Delivers instant Internet connectivity at millions of free and paid hotspot worldwide. After
accepting a one-time only terms and conditions (T&C) login, your Internet connections are on
auto-pilot as you roam the Wi-Fi hotspot universe—even as your mobile device sleeps. Combine it
with Intel® Smart Connect Technology and your favorite cloud content (email, social networks,
news, etc.) is automatically refreshed as you roam.


    Business-Class Wireless

Intel® vPro™ Technology7 Supports Intel’s hardware-based security and management features built into Intel® Core™ vPro™
processors and chipsets that enables IT to manage PCs virtually anywhere, anytime while
reducing deployment costs, improving security and ROI.
Intel® Active Management
Technology8
Using integrated platform capabilities and popular third-party management and security
applications, Intel® AMT allows IT or managed service providers to better discover, repair, and
protect their networked computing assets. Intel AMT is a feature of Intel® Core™ processors with
Intel® vPro™ technology.
Intel® PROSet/Wireless Software9 Combines simplified user interface design with advanced IT tools to improve security, reduce
complexity and save IT time and money. Streamlines client deployments and allows remote
management of wireless settings and profiles by IT managers.
Intel Location Based Service10 Enables seamless and accurate Wi-Fi indoor location service for employees to see campus maps
with reference to their location, locate the nearest resource (printer, conference, room, elevator,
etc.), or for asset tracking.



    Intel® Dual Band Wireless-AC 7265 Technical Specifications

General

Dimensions (H x W x D)
Weight
Diversity
Radio ON/OFF Control
Connector interface
LED Output
Operating Temperature (Adapter Shield)
Humidity Non-Operating
Operating Systems
Wi-Fi Alliance




IEEE WLAN Standard
Architecture
Roaming11

Bluetooth®
M.2 2230: 22 mm x 30 mm x 2.4 mm [1.5mm Max (Top Side)/ 0.1mm Max (Bottom Side)]
M.2 2230: 2.4g
Supported
Supported in both hardware and software
M.2: PCIe, USB
On/Off
0º to +80° C
50% to 90% RH non-condensing (at temperatures of 25°C to 35°C)
Microsoft Windows 7*, Microsoft Windows 8*, Linux* (most features not available on Linux)
Wi-Fi CERTIFIED* for 802.11ac, Wi-Fi CERTIFIED* a/b/g, Wi-Fi CERTIFIED* n, WMM*, WPA*, WPA2*, and WPS,
WPS 2.0, Protected Management Frames,
Wi-Fi Direct* for peer to peer device connections
Wi-Fi Miracast Source
IEEE 802.11abgn, 802.11ac, 802.11d, 802.11e, 802.11i, 802.11h, 802.11w
Infrastructure and SoftAP; Supports simultaneous Client and SoftAP modes
Supports seamless roaming between respective access points
(802.11b, 802.11g, 802.11a/b/g, 802.11a/b/g/n, and 802.11ac)
Dual Mode Bluetooth® 2.1, 2.1+EDR, 3.0, 4.0 (BLE)


Security12

Authentication
Authentication Protocols
Encryption
Wi-Fi Direct* Encryption and Authentication
Product Safety
Management Frame Protection
WPA and WPA2, 802.1X (EAP-TLS, TTLS, PEAP, LEAP, EAP-FAST), EAP-SIM, EAP-AKA
PAP, CHAP, TLS, GTC, MS-CHAP*, MS-CHAPv2
64-bit and 128-bit WEP, AES-CCMP, TKIP
WPA2, AES-CCMP
UL, C-UL, CB (IEC 60950-1)
802.11w (WFA- Protected Management Frames)

  1. Based on the theoretical maximum bandwidth enabled by 2x2 802.11ac implementations. Actual wireless throughput and/or range will vary depending on your specific operating system,
    hardware and software configurations. Check with your PC manufacturer for details.
  2. InstantGo is a Microsoft Windows OS feature in 8.1(known as Connected Standby in Microsoft Windows 8 and Microsoft Windows RT).
  3. Intel® Wireless Display requires an Intel® Wireless Display enabled PC, tablet, or smartphone, a compatible adapter, and a TV. 1080p and Blu-Ray* or other protected content playback only available on select
    Intel® processors with built-in visuals enabled. Consult your PC manufacturer. For more information, see www.intel.com/go/widi
  4. Intel® Smart Connect Technology requires a select Intel® processor, Intel® software and BIOS update, Intel® Wireless adaptor, and Internet connectivity. Solid state memory or drive equivalent may
    be required. Depending on system configuration, your results may vary. Contact your system manufacturer for more information.
  5. Intel WiFi Hotspot Assistant requires an Intel wireless adapter, Intel® PROSet/Wireless WiFi Software v15.6 or later, and an Internet connection for initial setup with the Easy WiFi* network.
  6. Intel® vPro™ Technology is sophisticated and requires setup and activation. Availability of features and results will depend upon the setup and configuration of your hardware, software and IT environment.
    To learn more visit: http://www.intel.com/technology/vpro
  7. Requires activation and a system with a corporate network connection, an Intel® AMT-enabled chipset, network hardware and software. For notebooks, Intel® AMT may be unavailable or limited over a host
    OS-based VPN, when connecting wirelessly, on battery power, sleeping, hibernating or powered off. Results dependent upon hardware, setup & configuration. For more information, visit
    http://www.intel.com/technology/platform-technology/intel-amt
  8. Intel® PROSet/Wireless Software may not be supported by your PC manufacturer. Check with your PC manufacturer for details on availability.
  9. Intel Location Based Service requires selected Intel wireless adapters and Intel® PROSet/Wireless WiFi Software v15.6 or later on Intel® 4th Gen Core processor-based PCs only.
  10. Roaming is supported only within each respective band and mode of access points.
  11. Some security solutions may not be supported by your PC’s operating system and/or by your PC manufacturer. Check with your PC manufacturer for details on availability.
  12. Microsoft Windows 7 and Microsoft Windows 8.

Copyright © 2014 Intel Corporation. All rights reserved.
