Home > Product > mPCIe to PCI-E Adapter > MP1
  MP1
(Mini PCI-E / PCI-E Adapter)
ADP substitution.

Introduction:
The PCI-E Mini Card passive adapter is designed for desktop PCs that converts Mini-Card to USB port or standard PCI-Express 1x slot.
You can insert your USB type minicard to this adapter then plug to USB port through USB cable.
Or insert your PCI-E type mini-card into this adapter then insert to PCI-E 1x connector.

MP1 with Intel® Turbo Memory


    Features

  • Mini PCI express to PCI express 1x converter.
  • Allows user to test PCI Express Mini modules on the PCI Express slot.
  • Allow user to test USB Mini-card modules on the USB port.
  • Supports two primary system bus interface: PCI Express and USB
  • Supports all of Mini-Cards such as 3G,CDMA, WLAN,WWLAN, MODEM Mini Card to desktop PC.

Notice
There are existing mPCIe 'form factor' SSD's that present SATA and PATA interface, but none that use the standard mPCIe pinout (i.e. mPCIe tx/rx pins). ...
MP1 support standard mPCIe minicard. Can?�t support custom SATA/PATA SSD minicard.
Please check compatibility list for detail.



    System Requirements

  • PCI-Express 1x slot and USB port
  • Windows 2000, XP, Vista 32/64,Windows 7
  • Linux

MP1
Unit price: USD 60.

MP1
(Mini PCI-E / PCI-E adapter) x1
Y05-U04-060
(USB 2.0 A Male to B Mini 5 Pin Cable) x1
Screw x2



OPTION Metal Baffle
Unit price: USD 2.

Metal Baffle
(Half to Full miniCard Bracket) x1
Screw x4



MPxx products functions comparison

MP1

MP2

MP2W

MP2A

Converts Mini-Card to USB port or standard PCI-Express 1x slot.

Supports Standard Height PCI Express bracket

Supports Low Profile PCI Express bracket





Support Full-Mini Card dimension

Support Half-Mini Card dimension



Add u.FL/IPX to RP-SMA pigtail WiFi RF cable





Add SIM card connector









Documents Download
Brief(PDF):  Taiwan 1   Taiwan 2 Mirror   China Mirror
